Single Girder Gantry Cranes Design Advantage-Jinrui Machinery

Henan Jinrui Machinery Company, Henan Jinrui Machinery Company;located in crane hometown of China, begins its manufacturing from 1981. We devoted to design,gantry crane design; manufacturing, sales, installation of industrial light-small type gantry crane manufacturer; hoisting equipment with whole process and integrated solutions.

Safe working load: 1T to 20T

Spans: 7m to more than 31.5m

Lifting heights: As per customer specifications

Design standards: M5, M7, M8 as per IS 3177/IS 807

* If the Single Girder Gantry Cranes are used in where the capacities are over 20 tons or spans is more than 30m, will be customized, and we will need the photo of worksite or offer drawing after field visit.

* Single Girder Gantry Cranes are generally used where an extremely high hook lift is required for the simple reason that the hook can be pulled up between the girders.

* These Single Girder Gantry Cranes are also used where high speeds and heavy services are required; or where the Single Girder Gantry Cranes needs to be fitted with walkways, crane lights, cabs, magnet cable reels or other special equipment.

* The Single Girder Gantry Cranes offer exceptional load capacity with a minimum dead weight, high stability and design rigidity, exceptional travel characteristics and minimum wear.

* The low-dead weight makes our cranes cost effective. To successfully cater to the diversified needs of our clients, we have utilized our resources to fabricate the most optimum range of double girder cranes. These are accurately designed with multiple hoisting trolleys running on the same bridge.

* Our range is known for its operational fluency, longer service life and high efficiency.
